Dimensions: 35,2 x 128,6 x 225,2 mm
Material front panel:metal (AlMg1)
Material master module: plastic (PC+ABS halogen-free, UL 94 V-0)
Color front panel: metal color
Color master module: medium gray (NCS 2502-B)
Mounted with screws 12 x
Delta insertion loss: ≤ 0.2 dB, testing method acc. to IEC 61300-3-4
Mating cycles: min. 500
Pull-out force: min. 70 N
Assembled with 12 x
Pigtail with semi-tight buffer PA/PBT, Ø 0.9 mm, blue, multimode G62.5 62.5/125 µm (OM1), length 2.5 m. Fitted with SC connector in acc. with IEC 61754-4. Zirconia (ceramic) ferrule with a PC polished endface geometry. Connector qualified in acc. with IEC 61753-1 for category U (uncontrolled environment). Beige connector housing, (multimode), material PBT / UL 94 V-0, black strain relief, material TPE / UL 94 V-0 and dust cover, material plastic.
Optical specifications (random mated):
Performance:
Insertion loss (IL) Grade Bm for 100% of the tested specimen: ≤ 0.50 dB / typical ≤ 0.15 dB
Return loss (RL) Grade 3: ≥ 35 dB
Mechanical specifications:
Mating cycles: delta IL < 0.2 dB after 500 mating cycles
Pull-out force fiber pigtail: ≥ 5 N
Insertion loss (IL) Grade Bm for 100% of the tested specimen: ≤ 0.50 dB / typical ≤ 0.15 dB
Return loss (RL) Grade 3: ≥ 35 dB
Mating cycles: delta IL < 0.2 dB after 500 mating cycles
Pull-out force fiber pigtail: ≥ 5 N
