Polaris 24 housing

Up to 144 splice connections on twelve trays: The Polaris 24 housing knows how to impress with its enormous packing density. The second largest member of the Polaris family combines capacity and flexibility - with convenient handling.

7  products

  • Polaris-box 24 SCM

    Polaris-box 24 SCM

    The Polaris-box 24 SCM inlay has a capacity for up to 24 FMTS-30 splice traysand an easy (click-on) mountable adapter bracket for 12/24 patch connections (SC, LCD). The modular, as set available overlength brackets allow an easy storage of loose tube (loop) or drop cable overlengths.

  • Polaris-box 24 SCM with lock

    Article no.: R895055

  • Polaris-box 24 SCM without lock

    Article no.: R895056
  • Polaris-box 24

    Polaris-box 24

    Polaris-box 24 with external mounting points equipped with a swiveling fiber inlay.

    On the top rigth side adapter field for up to 24 adapter LC-D, SC or E-2000.

    On the top left side splice area for up to 144 splice with 12 x 1TPU 12 x crimp (ANT) or 12 x shrink (HS) FMTS trays.

    Additional fiber storage are below the fiber inlay.

    Max. Capacity: 144 splices connections and 24 adapters

  • Polaris-box 24 with lock

    Article no.: R851087

  • Polaris-box 24 without lock

    Article no.: R851086

The Polaris Box 24 is the ideal solution for small and also for large projects in terms of flexibility and cable routing as well as dimension and capacity. When fully equipped24 SCE-2000™ or LC duplex couplers or 48 LC connectors can be connected. The 12 TPU (Tray Position Units) interfaces can be individually equipped with splice or splitter cassetteswhich gives you the possibility to customize the box according to your requirements. Secure management of subscribers and the number of fibers is straightforward thanks to the new FMTS (Fiber Management Tray System) system. The Polaris 24 enclosure's pivoting fiber tray provides secure separation of incoming and outgoing fibers and ample space for cable overlengths of bundled and drop cables. Routing and feeding cables through is also made easy with the Polaris 24 Box: the Polaris 24 Box's gentle bend radius protects cables from radius mismatch and unnecessary network errors. The FMTS system offers a unique concept for flexible and clear fiber assignment and separation of subscribers or other services.



Polaris-Box 24 - the innovative solution for your cable management



The Polaris-24 Box's new FMTS system allows you to safely manage trays and fibers. With an operating temperature of-25°C to +85°CUV resistanceshock resistance and an easy-to-remove lidthe box is ideal for both indoor and outdoor use. The integrated lock gives you the security against unauthorized access. In additionthe Polaris-24 Box comes with an accessory setwhich includes cable ties for ideal installationwhich ensure the clarity of cable routing. In additionthe Polaris-24 Box offers the possibility to connect and combine several boxesthus upgrading the capacity at a later stage. The lid is simple and removablemaking maintenance and installation easy. If you have any questions about your Polaris-24 Boxplease feel free to contact our staff. We will be happy to help and advise you with any questions you may have.
